Specifications
| Display | 0.96inch OLED display |
| Light Source | Near infrared |
| Projector Resolution | 854*480 |
| Projection Size | Large, Medium, Small, Very Small |
| Proection Color | Black white, green, green background, red, purple, purple background |
| Projection Brightness | 4 levels adjustable |
| Projection Mode | Normal,enhanced,depth |
| Depth Prompts | Deep, medium, shallow |
| Resolution Speed | 60frames/s |
| Resolution Deviation | ≤0.10mm |
| Best Projection Distance | 200+20mm |
| Min. identified blood vessel diameter | 0.4mm |
| Wave Length | 750-950nm |
| Maximum detection depth | ≤8mm |
| Sleeping mode | 30 minutes no operation |
| Main unit consumption | 50VA |
| Power | 100~240V,5060HZ,Adapter:12V,2.5A Battery: 2200mAh, working time >2.5h |
| Net Weight | 0.6kg |
| Dimension | 220mm*65mm*65mm |
