Pocket Wireless B/W Ultrasound Scanner

Model No : ZM-U146
Features : B/W Ultrasound Probe

Description&Specification

Specifications

Scan mode	Electronic Convex Array Scanning
Display mode	B, B/M
Frequency	Convex probe 3.2/5.0MHz
Elements	80 elements
Scanning Depth	Convex 90-200mm, adjustable
Field of view	Convex R60
Measure	Distance, area, obstetrics and other
Battery	Built-in lithium battery, 4200mAh, charging time 3 hours
Working system	iOS, Android, Windows
Image gray scale	256 levels
Noise reduction	0-1-2-3-4
Gain	30db-105db
Image/Video Storage	Store on mobile phones, Tablet PC
Dynamic Range	40/50/60/70/80/90/100/110
Produce size	1566020mm
Product weight	250g

label: Palm Ultrasound Wireless Ultrasound
