Mini Doppler Ultrasound USB Probe Scanner

Model No : ZM-U130
Features : Adjustable Scanning Depth

Description&Specification

Scan mode	Electronic Array, convex with cardiac namely phased array or linear array scanning
Display mode	B, B/M, color, PDI, PW
Frequency	Micro-Convex probe 5.0/7.0MHz, Linear probe 10/12MHz
Elements	128 elements
Scanning Depth	Micro-Convex 60-160mm, Linear 20-80mm, adjustable
Field of view	Linear L40, Micro-Convex R20
Measure	Length, Area, Obstetrics
Battery charge	by USB charge or wireless charge, charging time 2 hours
Working system	Apple iOS and Android, Windows
Image gray scale	256 levels
Frame rate	18f/s
Gain	30db-105db
Image/Video Storage:	Store on mobile phones, Tablet PC
Dynamic Range	40/50/60/70/80/90/100/110
Produce size	1566020mm
Product weight	250g

label: Mini Doppler Ultrasound Pocket Scanner
